Type
Desmosedici Stradale 90° V4, rearward-rotating crankshaft, 4 Desmodromically actuated valves per cylinder, liquid cooled
Displacement
1,103 cc
Bore and stroke
81 x 53.5 mm
Compression Ratio
14.0:1
Power
153 kW (208 hp) @ 13,000 rpm
Torque
123 Nm (90.4 lb-ft) @ 9,500 rpm
Fuel injection
Electronic fuel injection system. Twin injectors per cylinder. Full ride-by-wire elliptical throttle bodies
Exhaust system
4-2-1-2 system, with 2 catalytic converters and 4 lambda probes
Gearbox
6 speed with Ducati Quick Shift (DQS) up/down EVO 2
Primary drive
Straight cut gears; Ratio 1.80:1
Ratios
1=38/14 2=36/17 3=33/19 4=32/21 5=30/22 6=30/24
Final drive
Chain; Front sprocket 15; Rear sprocket 42
Clutch
Hydraulically controlled slipper and self-servo wet multiplate clutch. Self bleeding master cylinder
Frame
Aluminium alloy "Front Frame"
Front suspension
Öhlins NIX30 43 mm fully adjustable fork with TiN treatment. Electronic compression and rebound damping adjustment with Öhlins Smart EC 2.0 event-based mode
Front wheel
3-spokes forged aluminium alloy 3.50" x 17"
Front tyre
Pirelli Diablo Rosso IV Corsa 120/70 ZR17
Real suspension
Fully adjustable Ohlins TTX36 unit. Electronic compression and rebound damping adjustment with Öhlins Smart EC 2.0 event-based mode. Aluminium single-sided swingarm
Rear wheel
3-spokes forged aluminium alloy 6.00" x 17"
Rear tyre
Pirelli Diablo Rosso IV Corsa 200/60 ZR17
Wheel travel
120 mm (4.7 in) - 130 mm (5.1 in)
Front brake
2 x 330 mm semi-floating discs, radially mounted Brembo Monobloc Stylema® (M4.30) 4-piston calipers with Cornering ABS EVO. Self bleeding master cylinder
Rear brake
245 mm disc, 2-piston caliper with Cornering ABS EVO
Instrumentation
Last generation digital unit with 5" TFT colour display
Kerb weight
197,5 kg (434 lb)
Wet weight
193 kg (no fuel)
Seat height
845 mm (33.3 in)
Wheelbase
1.488 mm (58.6 in)
Rake
24,5°
Trail
100 mm (4 in)
Fuel tank capacity
17 l - 4.49 gallon (US)
Number seats
Dual seats
Safety equipment
Riding Modes, Power Modes, Cornering ABS EVO, Ducati Traction Control (DTC) EVO 2, Ducati Wheelie Control (DWC) EVO, Ducati Slide Control (DSC), Engine Brake Control (EBC) EVO 2, Auto tyre calibration
Standard equipment
Ducati Power Launch (DPL), Ducati Quick Shift (DQS) up/down EVO 2, Full LED lighting with Daytime Running Light (DRL), Ducati Electronic Suspension (DES) EVO with Ohlins suspension and steering damper, Quick adjustment buttons, Auto-off indicators, Marchesini aluminium forged wheels, Lithium-ion battery, Passenger seat cover
Provided equipment
Passenger seat and footpegs
Ready for
Ducati Data Analyser+ (DDA+) with GPS module, Ducati Multimedia System (DMS), Anti-theft, Heating grips
Warranty
24 months unlimited mileage
Valve clearance check desmo
-
Valve clearance check
24,000 km (15,000 mi)
Standard
Euro 5
Co emissions
178 g/km
Consumption
7.6 l/100km
Notes
Only for countries where Euro 5 standard applies
