Type
Superquadro: 90 ° V2, Desmodromic 4 valves per cylinder, liquid cooled
Displacement
955 cc
Bore and stroke
100 x 60,8 mm
Compression Ratio
12.5:1
Power
112,3 kW (153 CV) @ 10.750 giri/min
Torque
101,4 Nm (74,8 lb-ft) @ 9.000 rpm
Fuel injection
Electronic fuel injection system. Twin injectors per cylinder. Full ride-by-wire elliptical throttle bodies
Exhaust system
2-1-2-1 system, with 2 catalytic converters and 2 lambda probes
Gearbox
6 speed with Ducati Quick Shift (DQS) up/down EVO 2
Primary drive
Straight cut gears; Ratio 1.77:1
Ratios
1=37/15 2=30/16 3=27/18 4=25/20 5=24/22 6=23/24
Final drive
Chain; Front sprocket 15; Rear sprocket 45
Clutch
Hydraulically controlled slipper and self-servo wet multiplate clutch. Self bleeding master cylinder
Frame
Monocoque Aluminium
Front suspension
Fully adjustable Showa BPF fork. 43 mm chromed inner tubes
Front wheel
5-spokes light alloy 3.50" x 17"
Front tyre
Pirelli Diablo Rosso IV 120/70 ZR17M
Real suspension
Fully adjustable Sachs unit. Aluminium single-sided swingarm
Rear wheel
5-spokes light alloy 5,50” x 17”
Rear tyre
Pirelli Diablo Rosso IV 180/60 ZR17M
Wheel travel
120 mm (4.72 in) - 130 mm (5.12 in)
Front brake
2 x 320 mm semi-floating discs, radially mounted Brembo Monobloc M4.32 4-piston calipers with Bosch Cornering ABS EVO. Self bleeding master cylinder
Rear brake
245 mm disc, 2-piston caliper with Bosch Cornering ABS EVO
Instrumentation
Digital unit with 4,3" TFT colour display
Kerb weight
200 kg (441 lb)
Wet weight
193 kg (no fuel)
Seat height
845 mm (33,3 in)
Wheelbase
1.465 mm (57,7 in)
Rake
24°
Trail
94 mm (3.70 in)
Fuel tank capacity
17 l - 4.5 gallon (US)
Number seats
Dual seat
Safety equipment
Riding Modes, Power Modes, Bosch Cornering ABS EVO, Ducati Traction Control (DTC) EVO 2, Ducati Wheelie Control (DWC) EVO, Engine Brake Control (EBC) EVO, Auto tyre calibration
Standard equipment
Ducati Quick Shift (DQS) up/down EVO 2, Full LED lighting with Daytime Running Light (DRL), Sachs steering damper, Auto-off indicators
Ready for
Ducati Data Analyser+ (DDA+) with GPS module, Ducati Multimedia System (DMS), Ducati LinkApp, Anti-theft
Warranty
24 months unlimited mileage
Valve clearance check desmo
24,000 km (15,000 mi)
Standard
Euro 5
Co emissions
139 g/km
Consumption
6 l/100 km
