Type
Ducati Testastretta 11°, L-Twin cylinders, Desmodromic valvetrain, 4 valves per cylinder, liquid cooled
Displacement
937 cc
Bore and stroke
94 x 67.5 mm
Compression Ratio
13.3:1
Power
110 hp (81 kW) @ 9,250 rpm
Torque
92 Nm (68 lb-ft, 9.4 kgm) @ 6,500 rpm
Fuel injection
Bosch electronic fuel injection system, Ø53 mm throttle bodies with ride-by-wire system
Exhaust system
Stainless steel single muffler, catalytic converter and 2 lambda probes
Gearbox
6 speeds
Primary drive
Straight cut gears, ratio 1.85 : 1
Ratios
1=38/14, 2=31/17, 28=28/20, 4=26/22, 5=24/23, 6=23/25
Final drive
Chain, front sprocket Z15, rear sprocket Z49
Clutch
Slipper and self-servo wet multiplate clutch with hydraulic control
Frame
Tubular steel trellis frame
Front suspension
KYB Ø 46 mm upside-down fork, fully adjustable
Front wheel
Cross-spoked, tubeless, 2.15’’x21’’
Front tyre
Pirelli Scorpion Rally STR 90/90 - 21 M/C 54V M+S TL (A)
Real suspension
KYB monoshock, fully adjustable, remote preload adjustment, aluminium double-sided swingarm
Rear wheel
Cross-spoked, tubeless, 4.5’’x18’’
Rear tyre
Pirelli Scorpion Rally STR 150/70 R18 M/C 70V M+S TL
Wheel travel
230 mm (9.06 in) - 220 mm (8.66 in)
Front brake
2 x Ø 320 mm aluminium flange semi-floating discs, Radial mount Brembo monobloc 4-pistons calipers, Bosch Cornering ABS
Rear brake
Ø 265 mm disc, Brembo floating 2 pistons caliper, Bosch Cornering ABS
Instrumentation
5’’ TFT colour display
Kerb weight
223 kg (492 lb)
Wet weight
210 kg (no fuel)
Seat height
875 mm (34.4 in)
Wheelbase
1608 mm
Rake
27,6°
Trail
122 mm
Fuel tank capacity
21 l (5.54 US gal)
Number seats
2
Safety equipment
Ducati Safety Pack (Cornering ABS, Ducati Traction Control)
Standard equipment
Riding Modes, Power Modes, Ducati Wheelie Control (DWC), Engine Brake Control (EBC), Ducati Quick Shift up/down (DQS), Cruise control, full LED lighting system, DRL, Ducati brake light (DBL), USB power socket, 12V socket, self cancelling turn indicators, Steering damper
Ready for
Ducati Multimedia System (DMS), Antitheft system, Turn by turn navigation via app, fog lights, heated grips, auxiliary fuel tank
Warranty
48 months, unlimited mileage
Valve clearance check desmo
30,000 km (18,000 miles)
Standard
Euro 5
Co emissions
133 g/km
Consumption
5.6 l/100 km
Notes
Only for countries where Euro 5 standard applies
