Type
Desmosedici Stradale 90° V4, counter-rotating crankshaft, Desmodromic timing, 4 valves per cylinder, liquid-cooled
Displacement
1,103 cc (67.3 cu in)
Bore and stroke
81 mm x 53.5 mm (3.2 in x 2.1 in)
Compression Ratio
14.0:1
Power
218 hp (160.4 kW) @ 13,500 rpm
Torque
120.6 Nm (12.3 kgm, 89 lb ft) @ 11,000 rpm
Fuel injection
Electronic fuel injection system. Twin injectors per cylinder. Full ride-by-wire elliptical throttle bodies. Variable length intake system
Exhaust system
4-2-1-2 system, with 2 catalytic converters and 6 lambda probes (Euro 5+ Only)
Gearbox
6 speed with Ducati Quick Shift (DQS) up/down 2.0
Primary drive
Straight cut gears; Ratio 1.80:1
Ratios
1=36/15 2=34/17 3=33/19 4=32/21 5=30/22 6=27/22
Final drive
Chain 520; Front sprocket 17; Rear sprocket 42
Clutch
Hydraulically controlled slipper and self-servo wet multiplate clutch. Self bleeding master cylinder.
Frame
Aluminium alloy "Front Frame" with optimised stiffnesses
Front suspension
Öhlins NPX 25/30 (SV) S-EC 3.0 pressurised 43 mm fully adjustable fork with TiN treatment. Electronic compression and rebound damping adjustment with Öhlins Smart EC 3.0 event-based mode
Front wheel
5-spokes forged aluminium alloy 3.50" x 17"
Front tyre
Pirelli Diablo Supercorsa SP-V4 120/70 ZR17
Real suspension
Fully adjustable Öhlins TTX36 (SV) S-EC 3.0 unit. Electronic compression and rebound damping adjustment with Öhlins Smart EC 3.0 event-based mode. Aluminium Hollow Symmetrical Swingarm
Rear wheel
5-spokes forged aluminium alloy 6.00" x 17"
Rear tyre
Pirelli Diablo Supercorsa SP-V4 200/60 ZR17
Wheel travel
125 mm / 130 mm (4.9 in / 5.1 in)
Front brake
2 x 330 mm semi-floating discs, radially mounted Brembo Monobloc Hypure® 4-piston calipers with Race eCBS. Self bleeding master cylinder.
Rear brake
245 mm disc, 2-piston caliper with Race eCBS
Instrumentation
Digital unit with 6,9" TFT display and Optical Bonding - 1,280 x 480 px resolution
Wet weight
187 kg (no fuel)
Seat height
850 mm (33.5 in)
Wheelbase
1,477 mm (58.1 in)
Rake
24°
Trail
98 mm (3.9 in)
Fuel tank capacity
17 l (4.5 US gal)
Number seats
Single seat / Two seats, depending on country homologation
Safety equipment
Riding Modes, Power Modes, Ducati Slide Control (DSC), Bosch Cornering ABS, Ducati Brake Light (DBL), Vehicle Hold Control, Ducati Vehicle Observer (DVO), Ducati Traction Control (DTC) DVO, Ducati Wheelie Control (DWC) DVO, Dynamic Engine Brake (DEB), Race Brake Control, Tyre Calibration, Chain guard
Standard equipment
Ducati Quick Shift (DQS) up/down 2.0, Öhlins suspension, Lithium-ion battery, Quick adjustment buttons, Öhlins steering damper, Forged aluminium wheels, Coming Home, Single seat configuration, Cruise control, Ducati Electronic Suspension (DES) 3.0 with Öhlins Smart EC 3.0, Ducati Power Launch (DPL) DVO, TFT colour display, Full LED lighting system, Daytime Running Light (DRL), Self cancelling turn indicators, Lap Timer, Pit Limiter
Ready for
Anti-Theft, Tyre Pressure Monitoring System (TPMS), Ducati Data Logger (DDL), Ducati Multimedia System (DMS), Lap Timer Pro, Heated grips, Turn-by-Turn navigation system, USB port, GPS, Adjustable clip-ons height (+10 mm) - track use only
Warranty
24 months unlimited mileage
Valve clearance check
24,000 km (15,000 mi)
Standard
Euro 5+
Co emissions
151 g/km
Consumption
6,5 l/100 km
