Type
Ducati V4 Granturismo, V4 - 90°, 4 valves per cylinder, counter-rotating crankshaft, twin pulse firing order, semi dry sump, liqued cooled
Displacement
1,158 cc (71 cu in)
Bore and stroke
83 x 53,3 mm
Compression Ratio
14:1
Power
125 kW (170 hp) @ 10,750 rpm
Torque
121 Nm (12,3 kgm) @ 8,750 rpm
Fuel injection
Continental electronic fuel injection system, Øeq 46mm equivalent elliptical throttle bodies with Ride-by-Wire system
Exhaust system
Stainless steel muffler, double catalytic converter and 4 lambda probes
Gearbox
6 speed with Ducati Quick Shift up/down
Primary drive
Straight cut gears; Ratio 1.8:1
Ratios
1=40/13, 2=36/16, 3=34/19, 4=31/21, 5=29/23, 6=27/25
Final drive
Chain, Front sprocket z16; Rear sprocket Z42
Clutch
Multiplate clutch with hydraulic control. Self-servo action on drive, slipper action on over-run
Frame
Aluminium monocoque frame
Front suspension
Ø50 mm fully adjustable usd fork with internal stroke sensor. Electronic compression and rebound damping adjustment with Ducati Skyhook Suspension EVO (DSS)
Front wheel
Spoked wheel 3" x 19"
Front tyre
Pirelli Scopion Trail II 120/70 R19
Real suspension
Cantilever suspension with fully adjustable monoshock. Electronic compression and rebound damping adjustment. Electronic spring pre-load adjustment with Ducati Skyhook Suspension (DSS). Aluminium double-sided swingarm
Rear wheel
Spoked wheel 4,5" x 17"
Rear tyre
Pirelli Scorpion Trail II 170/60 R17
Wheel travel
200 mm - 200 mm (7,9 in - 7,9 in)
Front brake
2 x 330 mm semi-floating discs, radially mounted Brembo Stylema 4-piston calipers, 2-pad, radial master cylinder with cornering ABS as standard equipment
Rear brake
265 mm disc, 2-piston floating calliper, with cornering ABS as standard equipment
Instrumentation
6,5" TFT color dislay with Ducati Connect and full-map navi system
Kerb weight
260 kg (573 lb)
Wet weight
238 kg (no fuel)
Seat height
Adjustable 870 - 890 mm (34.3 - 35.0 in) 885 mm - 905 mm (34.9 in - 35.6 in) with high seat accessory 855 mm - 875 mm (33.7 in – 34.5 in) with low seat A accessory 825 mm - 845 mm (32.5 in – 33.3 in) with low seat B accessory 805 mm - 825 mm (31.7 in – 32.5 in) with low seat B + low suspension kit accessory* *Availability starting from November 2023
Wheelbase
1,572 mm (61,9 in)
Rake
24,7°
Trail
105,5 mm (4,15 in)
Fuel tank capacity
30 l (7,9 US gal)
Number seats
2
Safety equipment
Riding Modes, Power Modes, cornering ABS, Ducati Traction Control, Ducati Wheelie Control, Ducati Brake Light, Ducati Cornering Light, Vehicle Hold Control
Standard equipment
Ducati Skyhook Suspension EVO, Ducati Quick Shift, Cruise control, Hands-Free, Backlit handlebar switches, 6,5" TFT colour display with Ducati Connect and full-map navigation system, Full LED headlight with DRL, Engine Brake Control (EBC), Extended Cylinder Deactivation (ECD)
Warranty
48 months, unlimited mileage.
Valve clearance check
60,000 km (36,000 miles)
Standard
Euro 5
Co emissions
152 g/km
Consumption
6.6 l/100 km
Notes
*low suspension kit availability starting from November 2023
