Type
Testastretta 11°, L-Twin cylinder, 4 valve per cylinder, Desmodromic, liquid cooled, magnesium head covers.
Displacement
937 cc
Bore and stroke
94 x 67,5 mm (3,70 x 2,66 in)
Compression Ratio
13,3:1
Power
84 kW (114 hp) @ 9.000 rpm
Torque
96 Nm (71 lb-ft) @ 7.250 rpm
Fuel injection
Electronic fuel injection system, Ø 53 mm throttle bodies with full Ride by Wire system.
Exhaust system
Double under-tail aluminium muffler; catalytic converter and two lambda probes.
Gearbox
6 speed
Primary drive
Straight cut gears; Ratio 1.85:1
Ratios
1=37/15 2=30/17 3=28/20 4=26/22 5=24/23 6=23/24
Final drive
Chain; Front sprocket 15; Rear sprocket 43
Clutch
Slipper and self-servo wet multiplate clutch, hydraulic control.
Frame
Tubular steel Trellis frame
Front suspension
Marzocchi aluminium fully adjustable, upside-down Ø 45 mm.
Front wheel
Y shaped 3-spoke light alloy 3.5" x 17".
Front tyre
Pirelli Diablo Rosso III, 120/70 ZR17
Real suspension
Progressive linkage with adjustable spring preload and rebound damping Sachs monoshock. Aluminium single-sided swingarm.
Rear wheel
Y shaped 3-spoke light alloy 5.5" x 17"
Rear tyre
Pirelli Diablo Rosso III, 180/55 ZR17
Wheel travel
170 mm (6.7 in) - 150 mm (5.9 in)
Front brake
2 x 320 mm semi-floating aluminium flange discs, radially mounted Monobloc Brembo calipers, 4-piston 2-pad, radial pump with adjustable lever, with Bosch cornering ABS EVO.
Rear brake
245 mm disc, 2-piston caliper, with Bosch Cornering ABS
Instrumentation
Full-TFT colour display
Kerb weight
-
Wet weight
193 kg (no fuel)
Seat height
870 mm (34.2 in)
Wheelbase
1493 mm (58,8 in)
Rake
25°
Trail
104 mm (4.1 in)
Fuel tank capacity
14.5 l (3,8 US gallons)
Number seats
Dual seat
Safety equipment
Riding Modes, Bosch cornering ABS, Ducati Traction Control (DTC) EVO, Ducati Wheelie Control (DWC) EVO.
Standard equipment
Power Modes, Day Time Running Light (DRL), Tapered aluminium handlebars, Removable passenger footpegs, USB power socket.
Provided equipment
-
Ready for
Anti-theft system, Ducati Quick Shift (DQS) up/down, Heated grips, Ducati Multimedia System (DMS).
Warranty
-
Valve clearance check
30,000 km (18,000 mi)
Standard
Euro 4
Co emissions
122 g/km
Consumption
5,1 l/100 km
Notes
Only for countries where Euro 4 standard applies
